İzeltaş Yıldız Çakma Anahtar
570,49 TL
Yıldız Çakma Anahtar (mm) – 0750 Serisi
Krom Vanadyum çelikten üretilmiş, TS 3794 ve DIN 7444 standartlarına uygun yıldız çakma anahtarlar. Özel seriler için adet ve termin süresi isteyiniz.
| Kod | mm | L (mm) | a1 (mm) | b (mm) |  |
 |
|---|---|---|---|---|---|---|
| 0750 05 0024 | 24 | 160 | 15 | 41.5 | 235 | 1 |
| 0750 05 0027 | 27 | 180 | 16 | 45.5 | 325 | 1 |
| 0750 05 0030 | 30 | 190 | 17 | 51 | 43.5 | 1 |
| 0750 05 0032 | 32 | 190 | 17 | 51 | 425 | 1 |
| 0750 05 0036 | 36 | 205 | 19 | 58 | 550 | 1 |
| 0750 05 0038 | 38 | 205 | 19 | 58 | 530 | 1 |
| 0750 05 0041 | 41 | 225 | 20 | 63 | 730 | 1 |
| 0750 05 0042 | 42 | 225 | 20 | 63 | 700 | 1 |
| 0750 05 0046 | 46 | 240 | 22 | 71 | 970 | 1 |
| 0750 05 0047 | 47 | 240 | 22 | 71 | 930 | 1 |
| 0750 05 0050 | 50 | 255 | 23 | 77 | 1160 | 1 |
| 0750 05 0055 | 55 | 272 | 25 | 88 | 1520 | 1 |
| 0750 05 0060 | 60 | 272 | 25 | 88 | 1460 | 1 |
| 0750 05 0065 | 65 | 300 | 28 | 98 | 2025 | 1 |
| 0750 05 0070 | 70 | 330 | 32 | 108 | 2890 | 1 |
| 0750 05 0075 | 75 | 330 | 32 | 108 | 2755 | 1 |
| 0750 05 0080 | 80 | 360 | 35 | 126 | 4000 | 1 |
| 0750 05 0085 | 85 | 360 | 35 | 126 | 3620 | 1 |
| 0750 05 0090 | 90 | 390 | 40 | 140 | 5465 | 1 |
| 0750 05 0095 | 95 | 390 | 40 | 140 | 5250 | 1 |
| 0750 05 0100 | 100 | 420 | 44 | 148 | 6755 | 1 |
| 0750 05 0105 | 105 | 420 | 44 | 148 | 6445 | 1 |
| 0750 05 0110 | 110 | 450 | 48 | 166 | 8500 | 1 |
| 0750 05 0115 | 115 | 450 | 48 | 166 | 8460 | 1 |
| 0750 05 0120 | 120 | 490 | 54 | 178 | 10000 | 1 |
| ÖZEL SERİLER | ||||||
| *0700 05 0125 | 125 | 490 | 54 | 178 | 9900 | 1 |
| *0700 05 0130 | 130 | 518 | 59 | 196 | 16000 | 1 |
| *0700 05 0135 | 135 | 518 | 59 | 196 | 15900 | 1 |
| *0700 05 0140 | 140 | 518 | 59 | 196 | 15800 | 1 |
| *0700 05 0145 | 145 | 580 | 61.8 | 223 | 22000 | 1 |
| *0700 05 0150 | 150 | 580 | 61.8 | 223 | 21900 | 1 |
| *0700 05 0155 | 155 | 580 | 61.8 | 223 | 21800 | 1 |
| *0700 05 0160 | 160 | 580 | 61.8 | 223 | 21700 | 1 |
| *0700 05 0165 | 165 | 648 | 67 | 262 | 30000 | 1 |
| *0700 05 0170 | 170 | 648 | 67 | 262 | 29800 | 1 |
| *0700 05 0180 | 180 | 648 | 67 | 262 | 29700 | 1 |
